Control Arm Upper - Arm (Control/Trailing Arm Kit- wheel suspension)

Whiteline Control Arm Upper - Arm (Control/Trailing Arm Kit- wheel suspension)
Warranty:3 Year / 60,000Kms
This product includes the following components: 2 Arms

Benefit Note:

A short fall of the modern day IFS 4wd is the adjustment fits ranger provided for successful wheel alignments, this becomes efits ven more of an issue when the vehicle is lifted by more than 1 inch. Not only does the vehicle run into camber and caster issues, but ball joint articulation and clearance issues to the coil over strut at ride and droop height. The new Whiteline offset UCA (Upper Control Arm) is an all-in-one solution for any vehicle that has been lifted between 30mm and 70mm. Providing an increase between +2.5 and +3.5 degrees of caster and up to 1.5 degrees of negative camber increase (figures quoted are based off an approximate 50mm/ 2 inch) along with greater clearance to the coil over strut and more articulation of the arm by virtue of new maintenance free GIIRO bushing technology.
Product Information:
A short fall of the modern day IFS 4wd is the adjustment range provided for successful wheel alignments, this becomes even more of an issue when the vehicle is lifted by more than 1 inch. Not only does the vehicle run into camber and caster issues, but ball joint articulation and clearance issues to the coil over strut at ride and droop height. The new Whiteline offset UCA (Upper Control Arm) is an all-in-one solution for any vehicle that has been lifted between 30mm and 70mm. Providing an increase between +2.5 and +3.5 degrees of caster and up to 1.5 degrees of negative camber increase (figures quoted are based off an approximate 50mm/ 2 inch) along with greater clearance to the coil over strut and more articulation of the arm by virtue of new maintenance free GIIRO bushing technology.

Arm Type: Alignment
Units: Pair
Incl. Ball Joints: Yes
Adjustable: No
Alignment Type: Camber/Caster
Adjustment Type: Extended
On Car Adjustable: Not Applicable
Product Attribute: Bushing - Resistance
Product Attribute: Bushing - PTFE Lining
Product Attribute: Bushing - Mechanically Bonded
Product Attribute: Bushing - Adjustable
Product Attribute: Bushing - Fitter Friendly
Product Attribute: Bushing - Articulation Voids
Product Attribute: Alignment - Camber
Product Attribute: Alignment - Caster
Product Attribute: Finish - Powder Coated
Product Attribute: Warranty - 3 Year
Product Attribute: Install Guide

Fitment Position:
Fitment Difficulty:
Fitment Time (minutes):

Downloads

Fitting PDF Download

3 Year / 60-000Kms

Performance arms

By ordering this you will receifits ve the following components:

2 Arms

SKU	KTA246
Barcode #	9319924447657
Brand	Whiteline
Shipping Weight	7.0000kg
Shipping Width	23cm
Shipping Height	17cm
Shipping Length	43cm

Fits Lexus LX 570 (URJ201) fits 2007+
LEXUS LX 450d (VDJ201) 2015+
Fits Toyota LAND CRUISER 4.6 V8 (URJ202) 2012-2019
TOYOTA LAND CRUISER 4.7 V8 (UZJ200) 2007-2012
TOYOTA LAND CRUISER 4.5 D-4D (VDJ200) 2015+
TOYOTA LAND CRUISER 4.5 D-4D (VDJ200) 2007-2015
