Control Arm Lower Front and fits rear - Arm (Control/Trailing Arm Kit- wheel suspension)

Whiteline Control Arm Lower Front and fits rear - Arm (Control/Trailing Arm Kit- wheel suspension)
Warranty:3 Year / 60,000Kms
This product includes the following components: 4 Arms

Benefit Note:

This series of adjustable trailing arms are designed to modify fFits Actory camber - toe and track on the rear of Fits Subaru fits impreza and fits liberty. Use KTA107 as an economical solution for lack of rear toe adjustment particularly on Impreza GD-GH (MY01- on) series. This kit is supplied as 2x adjustable front arms and matching rear arm poly bushings. KTA108 and KTA109 utilise 4 complete adjustable arms with performance low compliance bushings. The result is greater fits ranger and more precise adjustment and a more direct connection between body and rear suspension delifits vering more predictable dynamic behaviour. Left-right-hand thread adjustment turn-buckle nut allows for easy on-car adjustment.
Product Information:
This series of adjustable trailing arms are designed to modify factory camber - toe and track on the rear of Subaru Impreza and Liberty. Use KTA107 as an economical solution for lack of rear toe adjustment particularly on Impreza GD-GH (MY01- on) series. This kit is supplied as 2x adjustable front arms and matching rear arm poly bushings. KTA108 and KTA109 utilise 4 complete adjustable arms with performance low compliance bushings. The result is greater range and more precise adjustment and a more direct connection between body and rear suspension delivering more predictable dynamic behaviour. Left-right-hand thread adjustment turn-buckle nut allows for easy on-car adjustment.

Arm Type: Alignment
Units: 2 x Pairs
Incl. Ball Joints: Not Applicable
Adjustable: Yes
Alignment Type: Camber/Toe
Adjustment Type: Turnbuckle
On Car Adjustable: Yes
Product Attribute: Bushing - Resistance
Product Attribute: Bushing - Lubricant
Product Attribute: Bushing - Knurling
Product Attribute: Bushing - Adjustable
Product Attribute: Alignment - Camber
Product Attribute: Alignment - Toe
Product Attribute: Finish - Powder Coated
Product Attribute: Warranty - 3 Year
Product Attribute: Install Guide

Fitment Position:
Fitment Difficulty:
Fitment Time (minutes):

Downloads

Fitting PDF Download

3 Year / 60-000Kms

Performance arms

By ordering this you will receifits ve the following components:

4 Arms

SKU	KTA108
Barcode #	9319924343492
Brand	Whiteline
Shipping Weight	6.0000kg
Shipping Width	20cm
Shipping Height	10cm
Shipping Length	59cm
Type	Recommended Retail Price (RRP)

Fits Subaru FORESTER 2.0 AWD (SF5) fits 2000-2002
SUBARU FORESTER 2.0 AWD (SF5) 1997-2000
SUBARU FORESTER 2.0 S Turbo AWD (SF5) 1998-2000
SUBARU FORESTER 2.0 S Turbo AWD (SF5) 2000-2002
SUBARU fits impreza 2.0 i 1998-2000
SUBARU IMPREZA 1.6 i (GC3) 1993-1998
SUBARU IMPREZA 1.6 i (GC3) 1997-2000
SUBARU IMPREZA 1.8 i (GC5) 1995-1996
SUBARU IMPREZA 1.8 i AWD (GC6) 1993-1996
SUBARU IMPREZA 1.6 (GC7) 1998-1998
SUBARU IMPREZA 2.0 i (GC7) 1996-1998
SUBARU IMPREZA 2.0 i AWD (GC7) 1996-1998
SUBARU IMPREZA 2.0 i AWD (GC8) 1999-2000
SUBARU IMPREZA 2.0 i fits wrx AWD (GC8) 1998-2000
SUBARU IMPREZA 2.0 i WRX AWD (GC8) 1992-1998
SUBARU IMPREZA 2.0 WRX / WRX STI AWD (GC8) 1999-2000
SUBARU IMPREZA 2.5 i AWD 2002-2005
SUBARU IMPREZA 1.6 i AWD 1993-1998
SUBARU IMPREZA 2.0 i 16V AWD 1998-2000
SUBARU IMPREZA 1.6 i (GF3) 1997-2000
SUBARU IMPREZA 1.8 i (GF5) 1995-1996
SUBARU IMPREZA 1.8 i AWD (GF6) 1993-1996
SUBARU IMPREZA 2.0 i AWD (GF8) 1996-1998
SUBARU IMPREZA 2.0 i WRX AWD (GF8) 1994-1998
SUBARU IMPREZA 2.0 i WRX AWD (GF8) 1998-2000
SUBARU IMPREZA 2.0 i 1995-2000
SUBARU IMPREZA 2.0 WRX / WRX STI AWD 1998-2000
SUBARU IMPREZA 2.2 i 1998-2000
SUBARU IMPREZA 2.5 AWD 1998-1999
SUBARU IMPREZA 2.0 i AWD 2000-2002
SUBARU IMPREZA 2.0 WRX AWD 2005-2006
SUBARU IMPREZA 2.5 AWD 2005-2008
SUBARU IMPREZA 2.0 i AWD (GG9) 2005-2007
SUBARU IMPREZA 2.0 i WRX AWD (GGA) 2000-2002
SUBARU IMPREZA 2.5 WRX AWD (GGG) 2005-2008
SUBARU fits liberty RS 4WD (BC5) 1991-1994
SUBARU LIBERTY 2.2 1989-1994
SUBARU LIBERTY GS Rally- Heritage 4WD (BC6, BC7) 1990-1994
SUBARU LIBERTY 2.2 i GX, LX, Heritage (BD6) 1994-1995
SUBARU LIBERTY 2.2 LX 4WD (BG6, BG7) 1994-1998
SUBARU LIBERTY 2.2 4WD (BD7) 1995-1998
SUBARU LIBERTY 2.2 i GX, LX, Heritage 4WD (BD7) 1994-1999
SUBARU LIBERTY 2.5 i RX Heritage 4WD (BD9) 1996-1998
SUBARU LIBERTY RS 4WD 1991-1994
SUBARU LIBERTY 2.2 i DX, GX, LX 1989-1994
SUBARU LIBERTY i GX 4WD 1989-1994
SUBARU LIBERTY 2.2 LX 1994-1998
SUBARU LIBERTY 2.2 GX, LX 4WD (BD6, BD7) 1994-1998
SUBARU LIBERTY 2.2 i (BG7) 1994-1996
SUBARU LIBERTY 2.2 i 4WD (BG7) 1994-1996
SUBARU LIBERTY 2.2 i 4WD (BG7) 1994-1998
SUBARU LIBERTY 2.5 i 4WD (BG9) 1996-1998
SUBARU OUTBFits AcK 2.5 1996-1998
SUBARU OUTBACK 2.5 (BG9) 1996-1999
